Comprehensive Test System for High Voltage Motors Insulation Resistance Temperature Rise and Load Performance Testing

System Introduction

SXDJ Motor Comprehensive Test System

The SXDJ Motor Comprehensive Test System is designed to provide centralized testing for AC motors, DC motors and variable-frequency motors. It covers motor capacities of 0–10,000 kW and voltage levels of 0–10 kV. The system is intended for use in motor manufacturing and for verification testing after repair.

Comprehensive Testing

The system covers multiple categories of motor testing. For electrical measurements, it can perform cold resistance measurement, no-load loss and no-load current measurement, as well as three-phase or single-phase voltage and average voltage measurement.

Withstand and insulation-related tests include inter-turn withstand voltage testing for high- and low-voltage motors, power-frequency withstand voltage testing and insulation resistance measurement. The system also supports vibration measurement, temperature measurement, temperature-rise testing and load testing.

Integrated System Design

The system combines an industrial computer with a test power supply system and test control system. Sensors and signal conditioning modules are integrated with data acquisition hardware and software for measurement signal collection. Numerical calculation and processing software is used together with graphical display and operation software to support the testing process.

Test report generation software is included for documentation. Waveforms and measurement results can also be stored and printed, providing a way to retain test information for later reference.

Operational Advantages

By integrating power supply, control, measurement and data processing functions, the SXDJ system provides a centralized platform for different motor test requirements. Its multi-channel configuration is suitable for applications requiring multiple measurement signals. The combination of data acquisition, numerical processing and graphical display supports systematic handling of test information.

Application

The system can be used in motor manufacturing plants for factory inspection and in motor repair facilities for post-repair testing. It is also applicable to electrical testing laboratories requiring a comprehensive platform for motor-related measurements and tests.

FAQ

Q1: Which motors can be tested with the SXDJ system?

A: The system is applicable to AC motors, DC motors and variable-frequency motors.

Q2: What tests are available?

A: Available tests include withstand voltage, inter-turn withstand voltage, resistance, no-load, voltage, vibration, temperature, temperature-rise, load and insulation resistance measurements.

Q3: Where can the system be used?

A: It is suitable for motor manufacturing, motor repair and electrical testing laboratory applications.
