Product Overview
The Customized Series Resonant Test System is designed for organizations building new high-voltage laboratories, expanding existing testing capacity, or upgrading their electrical testing equipment.
A successful laboratory project requires more than selecting an output voltage. The equipment must be matched to the test objects, capacitance, rated capacity, operating frequency, measurement requirements, available space, site power supply, and safety arrangements.
Our engineering team can help review the initial requirements and develop a suitable series resonant test configuration for compatible power cables, transformers, GIS, switchgear, and other capacitive electrical equipment.
The project scope can range from a standalone test system to a more comprehensive package including control equipment, measurement accessories, technical documentation, and agreed installation support.
Laboratory Project Solutions
New High Voltage Laboratory Construction
Define a suitable test system configuration based on the planned equipment under test, required voltage classes, waveform or frequency requirements, and laboratory infrastructure.
Existing Laboratory Upgrade
Review the current test equipment and identify possible requirements for system replacement, additional reactor sections, measurement upgrades, or digital control improvements.
Cable Testing Laboratory
Configure a suitable series resonant system for specified cable testing applications, taking account of cable length, capacitance, voltage, and operating frequency.
Transformer and GIS Test Laboratory
Evaluate the required system capacity and component arrangement for compatible transformer and GIS AC withstand testing.
Field Testing and Commissioning Projects
Consider modular equipment arrangements, transportation requirements, site power, grounding, and installation conditions.
Key Project Considerations
1. Electrical ratings
Define the required test voltage, rated capacity, current, operating frequency, and test duration.
2. Test-object characteristics
Provide cable length, cable capacitance, transformer parameters, GIS configuration, or other available electrical data.
3. Measurement requirements
Specify voltage measurement, monitoring, data recording, and reporting needs.
4. Laboratory layout
Review the available space, component positioning, electrical clearances, grounding, and access arrangements.
5. Safety and operating procedures
Confirm the required interlocks, protection functions, grounding provisions, and residual-charge management arrangements.
6. Project documentation
Clarify the required drawings, technical specifications, operating manuals, inspection documents, and commissioning records.
Frequently Asked Questions
Q1: Can you recommend a system before our laboratory design is complete?
Yes. Preliminary requirements can be reviewed first, followed by more detailed equipment selection as the laboratory design develops.
Q2: What information should we provide for an initial proposal?
Provide the intended test objects, voltage classes, required test voltage, capacitance or cable length where available, applicable standards, site conditions, and project stage.
Q3: Can you supply only the resonant test system without other laboratory equipment?
Yes. A standalone system or a broader package can be discussed according to the project's needs.
Q4: Can you provide layout drawings and technical documentation?
The available documentation can be defined in the agreed engineering and supply scope.
Q5: Can the system be expanded in the future?
Future expansion may be possible, depending on the system architecture, ratings, compatibility, and the planned additional test requirements.
Q6: How can we avoid choosing an unsuitable system?
Provide complete technical information as early as possible and confirm the proposed configuration against the actual test procedures, test-object capacitance, and applicable standards before placing the order.
Start Your High Voltage Laboratory Project
Whether you are constructing a new testing facility, expanding an existing laboratory, or upgrading an older AC withstand test system, we can help review your requirements and develop a suitable technical proposal.
Contact Sansion Power with your project details to discuss the system configuration, supply scope, delivery arrangements, and quotation.
