200kV 15kJ Lightning Impulse Generator and Test System for Power Transformer Insulation Withstand and Factory Type Testing

Product Description

200kV 15kJ Lightning Impulse Test System

The 200kV 15kJ Lightning Impulse Test System is intended for evaluating the impulse insulation withstand performance of power transformers and related high-voltage electrical equipment. It applies a standard 1.2/50μs lightning impulse waveform for insulation testing under specified test conditions.

For transformer manufacturing facilities, impulse testing is an important part of assessing insulation performance. The system combines impulse generation with a high-voltage divider and digital acquisition to measure and record waveform information. Its mobile platform configuration provides an alternative for testing environments where equipment mobility is required.

Product Parameters

Product Advantages

• Transformer Insulation Testing: Designed for applicable lightning impulse tests on transformer insulation systems.
• Standard Impulse Waveform: Uses the specified 1.2/50μs lightning impulse waveform.
• Waveform Recording: Digital acquisition supports recording of measured impulse waveforms.
• Mobile Configuration: Offers a mobile platform arrangement for suitable factory testing environments.

Application Scenarios

1. Power transformer manufacturing plants
2. Transformer quality control departments
3. Transformer insulation testing laboratories
4. High-voltage component manufacturers
5. Power equipment inspection facilities
6. Electrical testing centers
