High Voltage Motor Comprehensive Test Bench Motor Testing Equipment for No-Load Load Performance Insulation Resistance Withstand Voltage and Temperature Rise Testing

The High Voltage Motor Comprehensive Test Bench is designed for medium-voltage and high-voltage motor testing applications where conventional low-voltage motor test equipment cannot meet the required voltage and power range.

The system integrates motor performance testing with electrical insulation and withstand testing.

It can be configured according to the motor voltage class, power rating, speed, torque and required test standards.

• No-load test
• Load performance test
• Voltage measurement
• Current measurement
• Input power measurement
• Output power measurement
• Torque measurement
• Speed measurement
• Efficiency calculation
• Temperature measurement
• Temperature-rise test
• Insulation resistance test
• AC withstand voltage test
• Winding resistance test
• Starting performance test
• Locked-rotor test
• Overload test

• High-voltage induction motors
• Medium-voltage motors
• Large industrial motors
• Power plant motors
• Pump motors
• Compressor motors
• Fan motors
• Mining motors
• Steel mill motors
• Industrial drive systems

High-voltage motor testing often requires several different test functions and measurement systems.

Customers normally want to know:

• Can performance and electrical insulation tests be integrated?
• What voltage class can the system support?
• What motor power can be tested?
• Can the system test large industrial motors?
• Can test reports be generated automatically?
• Can the system be customized for our motor dimensions?

These parameters need to be confirmed before final system configuration.
