High Energy Impulse Voltage Generator and Lightning Impulse Test System for UHV Transformer, GIS, Cable and Electrical Insulation Testing

The High Energy Impulse Voltage Generator is engineered for demanding high-voltage and ultra-high-voltage testing applications.

The system uses a modular multi-stage architecture to achieve high impulse voltage and energy levels.

High-voltage systems currently available on the market cover configurations from approximately 100 kV to several MV, depending on the number of stages and design.

• UHV Transformer Testing
• GIS Testing
• High Voltage Cable Testing
• Insulator Testing
• Bushing Testing
• Switchgear Testing
• Surge Arrester Testing
• Electrical Insulation Research

• High-energy impulse generation
• Lightning impulse
• Switching impulse
• Chopped impulse
• Controlled charging
• Wave shaping
• High-voltage measurement
• Digital recording
• Safety interlocking
• Automatic discharge/grounding functions

• Generator dimensions
• Test bay height
• Electrical clearances
• Grounding
• Control room
• Safety fence
• Test object location

The generator configuration should consider the electrical characteristics of the test object. A generator's no-load voltage alone does not determine its actual performance under test conditions.

Q: Can you design the generator according to our laboratory?

A: Yes. The system can be engineered according to available laboratory dimensions, test voltage, test object and safety requirements.

Q: Can it be used for UHV equipment?

A: Yes. High-voltage and UHV impulse systems can be configured for appropriate test levels.

Q: Can the system be integrated with an existing test laboratory?

A: Yes. Integration with existing measurement, control and safety systems can be considered during engineering.
