Automatic Lightning Impulse Test System with Digital Control and Waveform Analyzer, High Voltage Impulse Generator for Transformer and Electrical Equipment Testing

Product Description

The Automatic Lightning Impulse Test System combines impulse voltage generation, digital control, waveform acquisition and test data management.

It is designed for laboratories where repeatable testing, efficient operation and reliable test records are important.

Modern impulse systems increasingly integrate computer-based charging, triggering, measurement, waveform recording and analysis.

Main Functions

• Automatic charging
• Automatic triggering
• Digital control
• Lightning impulse generation
• Switching impulse generation
• Chopped wave generation
• Real-time waveform acquisition
• Peak voltage calculation
• Front/tail time analysis
• Waveform comparison
• Data storage
• Test report generation
• Automatic test sequence

Application

Ideal for:

• Transformer factories
• HV test laboratories
• Research institutes
• Electrical equipment manufacturers
• Third-party testing laboratories
• University HV laboratories

Customer Pain Points

Manual Operation

Traditional high-voltage testing can involve multiple operating steps.

Digital control can coordinate charging, triggering, measurement and data recording.

Data Management

Customers often need to maintain historical test records for:

• Factory inspection
• Type tests
• Customer acceptance
• Quality control
• Certification
• R&D

FAQ

Q: Can the system be remotely operated?

A: A remote/digital control configuration can be provided according to project requirements.

Q: Can waveforms be saved?

A: Yes. Digital acquisition systems can record and store impulse waveforms and test parameters.

Q: Can test reports be generated automatically?

A: Automatic reporting can be included depending on the selected control and measurement software.
