IEC 60060 Lightning Impulse Test System and Impulse Voltage Generator for High Voltage Transformer, GIS, Cable, Bushing and Switchgear Testing

The IEC 60060 Lightning Impulse Test System is designed for high-voltage laboratories and electrical equipment manufacturers requiring standardized impulse testing.

The system can generate and measure controlled impulse voltage waveforms and can be configured according to the applicable requirements of IEC 60060 and relevant equipment standards.

Current industry systems frequently reference IEC 60060-1/2 and IEEE Std 4 for high-voltage impulse testing and measurement.

• Lightning Impulse LI
• Switching Impulse SI
• Chopped Lightning Impulse
• Full Wave Impulse
• Impulse Voltage Measurement
• Digital Waveform Acquisition
• Waveform Parameter Analysis
• Test Data Storage
• Automatic Report Generation

Depending on the test object and project, relevant standards may include:

• IEC 60060-1
• IEC 60060-2
• IEC 60076-3
• IEEE Std 4
• IEC 62271
• IEC 62067
• IEC 60840
• IEC 60502-2

Specific applicability should always be confirmed against the customer's latest project standard.

The correct approach is to provide a technical compliance matrix rather than simply saying “IEC compliant."

Impulse testing is not only about generating high voltage. The measurement chain, divider, recorder, bandwidth, calibration and waveform analysis are also important.

Q: Does the system support IEC 60060?

A: The system can be designed according to applicable IEC 60060 requirements.

Q: Does it support IEEE Std 4?

A: It can be configured according to applicable IEEE high-voltage test requirements.

Q: Can you provide calibration documentation?

A: Calibration and measurement documentation can be provided according to the selected measuring system and project requirements.
