Motor Performance Test System for High and Low Voltage AC DC Motors from 0 to 10000 kW and 0 to 10 kV with Interturn Withstand, Insulation Resistance, Load Temperature Rise, Torque, Speed Testing

Product Description

SXDJ Motor Test System

The SXDJ-ZT Electric Motor Performance Test System provides an integrated platform for comprehensive evaluation of high and low voltage motors. It is applicable to AC motors, DC motors and variable frequency motors with capacities from 0 to 10000 kW and voltage levels from 0 to 10 kV. The system combines insulation, withstand voltage, resistance, no-load, load, locked-rotor and temperature rise testing with torque, speed, vibration, temperature, voltage and current measurements.

Built around an industrial computer and integrated test control architecture, the Motor Performance Test System incorporates sensors, signal conditioning modules, data acquisition hardware and software, numerical processing and graphical display functions. Test waveforms and measurement results can be stored and printed, while generated reports provide organized records for factory inspection, maintenance verification and laboratory evaluation. Its modular and intelligent configuration supports different motor testing requirements.

Test Items

• High Voltage Motor Interturn Withstand Test
• Low Voltage Motor Interturn Withstand Test
• High Voltage Motor Power Frequency Withstand Test
• Low Voltage Motor Power Frequency Withstand Test
• Insulation Resistance Measurement
• Cold Resistance Measurement
• No-Load Loss Measurement
• No-Load Current Measurement
• Load Test
• Locked-Rotor Test
• Temperature Rise Test
• Torque Measurement
• Speed Measurement
• Vibration Measurement
• Temperature Measurement
• Three-Phase and Single-Phase Voltage Measurement
• Three-Phase and Single-Phase Current Measurement

Product Advantages

Comprehensive Electrical Evaluation

Covers insulation, resistance, withstand voltage, current and voltage measurements for motor inspection.

Performance Test Integration

Combines load, no-load, locked-rotor, torque, speed and temperature rise testing within one platform.

Intelligent Modular Architecture

Modular design allows the testing system to integrate different functions according to application requirements.

Measurement and Result Visualization

Graphical operation and numerical processing functions help operators review measured data and test results.

Application Scenarios

• High Voltage Motor Testing
• Low Voltage Motor Inspection
• Motor R&D Laboratories
• Motor Performance Evaluation
• Motor Repair Verification
• Electrical Testing Facilities
