200 kV 15 kJ Mobile Lightning Impulse Generator Test System for Power Transformer Insulation Type Tests and On-Site Electrical Equipment Evaluation

Product Description

200kV 15kJ Mobile Lightning Impulse Generator

The 200kV 15kJ Mobile Lightning Impulse Generator Test System is designed for customers requiring flexible impulse testing in different locations. Its portable configuration provides a practical solution for lightning impulse testing of power transformers, distribution transformers, switchgear, cables, bushings and other high voltage electrical equipment.

The system combines an impulse generator, charging unit, wave-shaping components, voltage divider, measurement and control functions. The mobile structure makes it suitable for transformer factories, testing laboratories, power utilities and field engineering projects where conventional fixed test equipment is less convenient.

Product Parameters

• Product Type: Mobile Lightning Impulse Generator Test System
• Rated Impulse Voltage: 200kV
• Impulse Energy: 15kJ
• Standard Waveform: 1.2/50μs
• Structure: Mobile Configuration
• Test Objects: Transformers, Switchgear, Cables, Bushings and Insulators
• Main Components: Impulse Generator, Charging Unit, Wave-Shaping Network, Voltage Divider and Control System
• Testing Function: Lightning Impulse and Insulation Testing
• Standard: IEC 60060 and Customer Requirements

Product Advantages

1. Mobile Configuration – Easier transportation and deployment for different test locations.
2. Integrated Test Equipment – Generation, measurement and control functions are combined in one system.
3. Compact Testing Solution – Suitable for projects where laboratory space and mobility are important.
4. Flexible Application – Supports factory, laboratory and field high voltage testing.

Application Scenarios

• Power Transformer Factories
• Distribution Transformer Testing
• High Voltage Laboratories
• Power Utility Field Testing
• Switchgear and Cable Testing
• Electrical Equipment Commissioning

FAQ

Q1: What is the main advantage of this system?

A: Its mobile configuration provides greater flexibility than a conventional fixed impulse testing system.

Q2: What products can be tested?

A: Typical test objects include transformers, switchgear, cables, bushings and insulators.

Q3: What does 200kV 15kJ mean?

A: 200kV is the rated impulse voltage and 15kJ is the impulse energy capacity.

Q4: Can the system be customized?

A: Yes. The system configuration can be designed according to the customer's test voltage, energy, test object and application.
