5kVA/50kV Power Frequency PD-Free AC Withstand Test System

The 5kVA/50kV Power Frequency PD-Free AC Withstand Test System is a professional AC high-voltage testing solution for maintenance organizations working with electrical power infrastructure. It can provide the required test voltage for insulation withstand verification before equipment is returned to operation, helping testing personnel identify insulation problems through controlled AC voltage application.

The system combines a Motorized Operation Console, Power Supply, PD-Free Test Transformer, and Voltage Divider. The motorized console allows operators to regulate the test voltage electrically, while the PD-free transformer supplies the high-voltage AC source. The voltage divider provides voltage feedback for the testing circuit. This configuration can be adapted to factory, laboratory, maintenance, and commissioning environments.

Product Parameters

Product Advantages

• Maintenance Application Focus — Suitable for organizations responsible for periodic inspection and repair of electrical equipment.
• Controlled AC Withstand Testing — Provides a defined power-frequency voltage for insulation verification.
• Low-Discharge Configuration — Helps reduce unwanted PD from the test transformer during testing.
• Electric Operating Console — Supports convenient voltage adjustment without relying on manual regulation.
• Measurement Capability — The voltage divider enables monitoring of the applied high voltage.
• Flexible Deployment — Can be configured for different testing locations and electrical equipment requirements.

Application Scenarios

• Railway electrical systems
• Railway power maintenance
• Electrical repair departments
• Power maintenance companies
• Field commissioning projects
• Utility equipment inspection
• High-voltage electrical maintenance

FAQ

Q1: Is this a conventional AC withstand test system?

A: It is a power-frequency AC withstand test system with a PD-free configuration, designed to provide a low-discharge high-voltage testing environment.

Q2: What type of operation console is supplied?

A: The standard configuration uses a motorized operation console for electric voltage adjustment.

Q3: What is the function of the PD-free transformer?

A: It generates the required high-voltage AC output while minimizing unwanted partial discharge from the test source.

Q4: What factors should be considered before ordering?

A: Customers should provide the required test voltage, test object, capacity/load characteristics, test duration, power supply conditions, and installation environment so the system can be correctly configured.
