GIS AC Resonant Test System Variable Frequency High Voltage Resonance Test Equipment for GIS Switchgear, Circuit Breaker and Substation Insulation Testing

Name: GIS AC Resonant Test System Variable Frequency High Voltage Resonance Test Equipment for GIS Switchgear, Circuit Breaker and Substation Insulation Testing
Brand: Sansion Power Electric Co., Ltd.
SKU: SXBP
Price: Negotiable USD
Availability: InStock

All Products

Transformer Test System
(17)

Electric Motor Test System
(15)

Temperature Rise Test Equipment
(30)

High Voltage Test System
(43)

AC Dielectric Test System
(55)

Impulse Voltage Generator
(40)

AC High Voltage Test Equipment
(13)

I'm Online Chat Now

GIS AC Resonant Test System Variable Frequency High Voltage Resonance Test Equipment for GIS Switchgear, Circuit Breaker and Substation Insulation Testing

Large Image : GIS AC Resonant Test System Variable Frequency High Voltage Resonance Test Equipment for GIS Switchgear, Circuit Breaker and Substation Insulation Testing

Product Details:

Place of Origin:	China
Brand Name:	Sansion Power
Certification:	CE/SGS/EMS/ISO 9001
Model Number:	SXBP

Payment & Shipping Terms:

Minimum Order Quantity:	1
Packaging Details:	Plywood Case
Delivery Time:	30 Working Days
Payment Terms:	L/C,T/T

Contact Now Chat Now

GIS AC Resonant Test System Variable Frequency High Voltage Resonance Test Equipment for GIS Switchgear, Circuit Breaker and Substation Insulation Testing

Description

Frequency Range:	20–300 Hz	Waveform Distortion:	Low
Protection Functions:	Over-voltage, Over-current, Flashover	Design:	Modular Structure
Voltage Level:	108kV	Test Type:	AC Withstand Voltage
Highlight:	GIS AC resonant test system , variable frequency high voltage test equipment , substation insulation testing equipment

Product Description

The GIS AC Resonant Test System is designed for high-voltage AC dielectric and withstand testing of Gas Insulated Switchgear and associated substation equipment.

GIS testing requires a stable high-voltage AC source with appropriate voltage capacity, measurement accuracy and protection functions.

A variable-frequency resonant system can be configured according to the GIS test object's capacitance and required test voltage.

Testing Functions

GIS AC withstand test
GIS dielectric test
GIS insulation verification
Circuit breaker AC test
Switchgear testing
Busbar testing
CT/PT testing
Insulator testing
Substation equipment withstand test

Key Features

Variable-frequency output
High-voltage modular reactor
Automatic resonance tuning
Digital control
High-voltage measurement
Overcurrent protection
Overvoltage protection
Flashover protection
Zero-start protection
Real-time monitoring

Modern series-resonant systems are specifically marketed for GIS, transformers, switchgear and other capacitive substation equipment.

FAQ

Q: Can this system test complete GIS sections?

A: Yes, when the system's voltage, capacity and test-object capacitance are appropriately matched to the GIS configuration.

Q: What determines the required system capacity?

A: The main factors include test voltage, GIS capacitance, test frequency, test duration and required current.
