Impulse Voltage Generator with Digital Measurement System Complete High Voltage Lightning Impulse Testing Solution with Voltage Divider, Oscilloscope and Control Software

Product Description

The Impulse Voltage Generator with Digital Measurement System provides a complete testing solution by integrating impulse generation and measurement technology.

The system includes the main impulse generator, DC charging power supply, high-voltage measurement divider, waveform acquisition equipment and analysis software.

The digital measurement system records the impulse waveform and processes important parameters automatically.

Complete System Configuration

A typical system may include:

• Lightning impulse voltage generator
• DC charging unit
• Impulse voltage divider
• Wavefront resistance
• Wavetail resistance
• Chopping device
• Digital acquisition system
• Computer control system
• Waveform analysis software
• Safety grounding system

Software Functions

• Real-time waveform display
• Automatic parameter calculation
• Waveform storage
• Waveform comparison
• Waveform zoom
• Test record management
• Data export
• Automatic report generation

FAQ

Q: Why is a voltage divider important?
A: The voltage divider is part of the high-voltage measurement chain used to scale the impulse voltage to a level suitable for the measuring system.

Q: Can the system work with a digital oscilloscope?
A: Yes. Depending on the configuration, waveform acquisition can use a dedicated impulse measuring system or compatible digital acquisition equipment.
