Transformer Comprehensive Test System with Automated Measurement and Control for Power Transformer Manufacturing and Maintenance

Product Description

The SXBZ Series Transformer Comprehensive Test System is a configurable testing solution for organizations that need to perform multiple electrical tests on transformers in a structured and repeatable way.

Designed around the complete testing process, the system brings together test power, voltage regulation, electrical measurement, signal acquisition, control, protection, and data management.

Components

Central Control Console

The main operating station for controlling the configured testing equipment and monitoring the testing process.

Measurement Cabinet

Used for centralized acquisition and measurement of transformer electrical parameters.

Power Analysis Unit

Provides measurement and analysis of relevant electrical power parameters.

Voltage & Current Sampling Unit

Collects the required electrical signals during testing.

Voltage Regulator

Provides controlled and adjustable test voltage for the testing circuit.

Intermediate Transformer

Used to match voltage and current requirements within the test circuit.

Test Transformer

Provides the required test voltage for the configured testing application.

Motor-Generator Set

Can be incorporated where a dedicated test power source is required.

Distribution & Control Cabinet

Handles system power distribution, switching, control, and related protection functions.

Typical functions

1. Transformer Electrical Measurement
   Measurement of voltage, current, and other electrical parameters.
2. Power Parameter Testing
   Acquisition and analysis of relevant power parameters.
3. Winding DC Resistance
   Measurement of transformer winding resistance through the configured resistance testing unit.
4. Turns Ratio Measurement
   Testing of transformer turns ratio using the corresponding measurement module.
5. Test Signal Acquisition
   Collection of voltage and current signals during the testing process.
6. Customized Test Functions
   Additional testing functions can be incorporated according to project requirements.

Technical Information

FAQ

1. Why use a comprehensive transformer test system instead of separate instruments?

A comprehensive system allows several testing and supporting functions to be organized within one testing platform.
This can simplify equipment operation, reduce repeated connections, and provide a more structured workflow for facilities performing multiple transformer tests.

2. Is SXBZ suitable for transformer production lines?

Yes.The system is suitable for transformer factories that require repeated testing during production, inspection, and final quality control.
Its configuration can be adapted to the transformer specifications and production testing process.
